Large custom high contrast display.
- Auto lock out if test resister overheats.
- Voltage indication.
- Measure low loop with 0.01 W resolution.
- High loop range permit measurement of ground spikes.
- Microprocessor controlled.
| Loop Impedance Range | 20 / 200 / 2000 W |
| Loop Impedance Accuracy | +/- ( 2% + 2dgts ) at 1 W on 20 W Range |
| Lowest Resolution | 0.01 W |
| Voltage Display | +/- 2% + 1digit |
| Ac Test Current | 25A nominal at 20 Range |
| Ac Test Period | 20ms |
| PSC Range | 200A / 2000A / 20KA |
| Operating Voltage | 230V +/- 10% , 50Hz +/- 1 % |
| Withstand Voltage | 3000V AC for 1 minute |
| Fuse Protection | HRC ceramic fuse |
| Dimensions | 200(L) x 140(W) x 95(H)mm |
| Weight | Approx. 900g |
| Display | 3 digit liquid crystal display with a maximum reading of 1999. |
| Over Range Indication | "" OL "" will be shown on the LCD Penal when out of range measurement is made. |
| Operating Temperature and Humidity | 0 ℃ to 40 ℃ (32℉ to 104 ℉), Below 80% RH |
| Storage Temperature | -10 ℃ to 60℃ (14 ℉ to 140 ℉) |
| Over Temperature | "" OL "" on "" |
| Accessories | Test Lead with IEC Connect |
